Manual Bottom Drive Carton Sealer


Our MBD line incorporates our exclusive 2″ or 3″ pop-out pressure-sensitive “High Speed” tape heads with BestPack’s patented tab adjustment. All BestPack units are available in our standard baked enamel finish and food grade 304 stainless steel for 21 CFR 110 compliance.

Features

  • Two Bottom Belt Drive
  • Telescopic Mast Design
  • Extra 4" Carton Height Adjustment Available on Upper Assembly
  • Adjustable Bed Height for: MBD22-2 & MBD22-3 - 23.5" to 30.0"
  • Upper Side Compression Unit
  • Height Adjustment Handle can be Mounted on Either Side of the Carton Sealer
  • Guide Rail Centering Mechanism
  • Tape Roll Lengths: 1,000 yd., 1,500yd., 2,000yd.

Specifications

Speed: Up to 30 Cartons/min.
Power Requirements: 110 Volts 60 Hz
Air Requirements: N/A
Shipping Weight  : 310 lbs
Machine Dimensions: (42.0") x (28.8") x (70.3")
Carton Range: (6.0" - U) x (6.5" - 20.0") x (3.0" - 20.25")
Trip Current (A): 10
FLA: 2.5
Conveyor Height Adjustment: (23.5" - 30.0")
Phase: 1
SSCR (KA): 5
Max Current: 2.5
Power (W): 275
Specifications Based On Line : Specifications based on MBD22-2

The BestPack™ MBD Series is an operator-fed, adjustable carton sealer designed to efficiently fulfill light to heavy duty uniform top and bottom sealing carton closure application needs. The two bottom belts are powered by an 110V UL-approved electric motor. The MBD Series is also designed with four adjustable legs for quick and easy height modification to suit the needs of your production lines. Dual telescopic masts allow for an extra 4″ carton height extension on the upper assembly.
